ERRECI
Electrochemistry
CONSORT
Electrochemistry - Electrophoresis
CONSORT has been producing tools for themeasurementOfpH, mV, Ion-selective, Conductivity, Salinity, Dissolved Oxygen, Temperature, benchtop, portable, or process. Erreci offers its scientific equipment to enable all companies, and especially analysis and scientific research laboratories, to analyze their samples with excellent results, at minimal cost, and with the guarantee of good control over the various phases.
Furthermore, many of the machines offered allow for total control by dedicated software and allow the operator to only perform a supervisory role.
The instrumental line also includes power supplies for electrophoresis androomsFordeterminationsOfDNA, RNA, Proteins, etc.
DISSOLVED OXYGEN METERS
The line ofreadersOfdissolved oxygen, includes various instruments designed to meet the needs of different operators; combined readers are available, both portable and laboratory, multi-parameter, classic compact readers with graphic display or readers for industrial plant or process control.
All models are able to read in different scales (mg/l or % saturation) with temperature reading,compensationOfsalinityand atmospheric pressure
CONSORT Z921T
Dissolved Oxygen: 0…60 mg/l (0.01 mg/l)
: 0…6000 % (0.1 %)
Temperature: 0…50°C (0.1°C)
Pressure: 8000…1100 hPa (1 hPa)
Automatic pressure compensation between 800 and 1100 hPa
- High resolution LCD graphic display 124 x 64 pixels for viewing titration curves
- Manual/automatic storage over time of 7200 readings with date and time for O2, % and temperature
- NiCd batteries for powerless work with charge indicator
- S241T temperature-compensated measuring electrode complete with 3 meters of cable.
MOLECULAR BIOLOGY INSTRUMENTATION AND ACCESSORIES
The line developed for MOLECULAR BIOLOGY includes electrophoresis power supplies, electrophoresis chambers, gradient mixers, gel dryers, transilluminators, shields and boxes for protection from gamma and beta rays and all the accessories combined with the items in the catalogue.
For more details on the different models, fill out the information request form
The different models cover the following ranges:
- Voltage: 0÷6000 V
- Current: 0÷2000 mA
- Power: 0÷300 W
- Temperature: 0÷100°C
- Timer: 0...999 min. / 0...99.9 h
- Automatic restoration of operating conditions in the event of a blackout
CONSORT P903
Microprocessor-controlled pH / mV / Temperature / Ion-selective reader,
complete with integrated graphic display
PORTABLE OR INDUSTRIAL MODELS AVAILABLE FOR COMBINED pH/EC/O2 MEASUREMENTS
- Automatic measurement ranges pH: -2.000...+16.000 pH mV: ± 0...2000.0 mV Ion-selective: 10-11...10+1 Direct concentration and increment methods Temperature: 0...+100.0 °C
- Resolution pH: 0.001 pH mV: 0.1 mV Temperature: 0.1 °C
- Inputs pH/mV/Ion.: BNC, 1012 Ohm + differential measurements Temperature: 1; 2 x banana plugs Pt 1000/Pt100
- Accuracy pH/mV/Ion.: 0.1% of reading
- Automatic or manual temperature compensation -30...+130 °C
- Programmable automatic or manual calibration pH: 1...5 points, up to 9 standards + 5 user-defined ISO-pH: 6...8 pH SLOPE: 80...120% mV: 1 point Ion-selective: 2...19 points; 5 calibration curves Temperature: ± 10 °C
- High-resolution graphic LCD display, 124 x 64 pixels, for viewing titration curves
- Manual/automatic storage of up to 7200 readings over time, with date and time, for pH, mV and temperature
- GLP compliant software with electrode calibration history
- Stability indicator
- Battery charge percentage indication
- Self-diagnosis at start-up
- “Hold display” function
- Manual resolution selection
- Analog output: 0...2 V
- Bidirectional RS232C output for external printer and/or PC
- Numerical identification of the sample and the instrument
- Personal access code to data and methods
- Data acquisition and transmission
- IP65 waterproof box
- NiCd batteries for powerless work with charge indicator
- Power supply 210...250 VAC, 50/60 Hz
- Dimensions and weight: 250 x 120 x 50 mm / 600 g
K911
Computerized dual-power conductivity meter complete with integrated graphic display and 4-pole conductivity cell
PORTABLE OR INDUSTRIAL MODELS AVAILABLE FOR COMBINED pH/EC/O2 MEASUREMENTS
- Automatic range readings Conductivity: 0...200 mS/cm Resistivity: 0...20 MW.cm Salinity: 0...100 mg/l Temperature: 0...+100.0 °C
- Resolution Conductivity: 0.01 µS/cm Resistivity: 10 W.cm Salinity: 0.01 mg/l Temperature: 0.1 °C
- Inputs Conductivity: 1 DIN-8 (4-electrode) with very high resolution Temperature: 1 DIN-8 (4-electrode) with very high resolution
- Accuracy 0.5% of reading
- Temperature compensation. Automatic or manual 0...100 °C
- Automatic or manual calibration with 3 predefined standards + 3 user-definable Temperature: ± 10 °C Temperature correction Cell constant: 0.3 to 1.3 cm-1 ± 30%, automatic calibration Temp. coefficient: NaCl curve Reference temp.: 20 or 25 °C Cal. solution: 1413 mS/cm - 12.88 mS/cm - 111.8 mS/cm + 3 user-definable
- High resolution LCD graphic display 124 x 64 pixels for viewing titration curves
- GLP compliant software with cell calibration history
- Signal stability indication and “hold display” function
- Self-diagnosis at start-up, possibility of checking electrode efficiency
- Programmable 0...2 V analog output
- RS232C output for external printer and/or PC
- Manual or automatic storage over time of 7200 readings with date and time for conductivity, resistivity or salinity and temperature
- IP65 waterproof case
- NiCd batteries for powerless work with charge indicator
- 4-electrode conductivity cell with constant K=1cm-1 complete with Pt1000 thermometer probe
- Power supply 210...250 VAC, 50/60 Hz
- Dimensions and weight: 250 x 120 x 50 mm / 800 g
